fischer Highbond Anchor FHB II-A L

From: £55.45

Using the fischer Highbond Anchor FHB II-A L in conjunction with resin or mortar, secures maximum loads in cracked and non-cracked concrete.

Get 15% off with a trade account.



Size Guide: Thread x Anchorage Depth/Usable Length

Product Description

The fischer Highbond Anchor FHB II-A L is a component of the FHB II system, which in conjunction with a fischer resin or mortar from the same system, secures maximum loads in cracked and non-cracked concrete. For example, large machines and heavy steel or timber constructions in internal areas. The Highbond Anchor is suitable for use with the following;

The fischer Highbond Anchor FHB II-A L is made from zinc-plated steel.

fischer Highbond Anchor Advantages

  • The large anchorage depth of the anchor rod allows the system to achieve maximum load values. Thus fewer fixing points and smaller anchor plates are required.
  • The cone shape of the rod has been specially optimised for high tensile loads. As a result, the anchor achieves the best performance in cracked concrete.
  • The FHB II-A L anchor is suitable for use both with capsules and with injection mortar. This guarantees maximum flexibility in the application.
  • No drill hole cleaning is necessary when using the FHB II-A L anchor in combination with either of the resin capsules. This saves precious installation time.
  • When using the anchor in combination with the injection mortar FIS HB, push-through installation with annular gap filling is possible without the use of any further tools.

fischer Highbond Anchor Functioning

  • The FHB II-A L is a bonded anchor with torque-controlled expansion for pre-positioned and push-through installation.
  • When using FHB II-A L in push-through installation, fill the annular gap with the injection mortar FIS HB.
  • Using either the specified resins or mortar listed above, fully bonds the anchor in the drill hole.
  • When tightening the hexagon nut, the anchor rod cones pull into the mortar shell, which expands against the drill hole wall.
  • The styrene-free vinyl ester mortar fully seals the drill hole.
  • When using the resin capsule, set the anchor rod through rotating and hitting motions with a hammer drill. Use the RA-SDS setting tool.

Building Materials

Below are some examples of installation for the fischer Highbond Anchor FHB II-A L within different wall types. If you are unsure of what type of wall you may have then please see our guide on What Type of Wall Do I Have?

Approved for:

  • Concrete C20/25 to C50/60, cracked and non-cracked

Also suitable for:

  • Concrete C12/15

Applications

Guard rails | Façades | Staircases | Steel brackets | Machines | Masts | Rash protection | Steelwork constructions | Timber constructions

Installation Examples

Below are some examples of installation for this product within different wall types. If you are unsure of what type of wall you may have then please see our guide on What Type of Wall Do I Have?

Concrete Installation with Injection Mortar

Concrete Installation with Resin Capsule

fischer Highbond Anchor Safety Data Sheet

fischer Highbond Anchor Load Ratings

fischer Highbond Anchor Installation Instructions
